Product Specifications
Operating Weight: ~20,330 kg
Engine: Cat 3066 ATAAC (or C6.4 for some variants)
Net Power: ~104 kW / 140 hp
Fuel Tank Capacity: ~410 L
Hydraulic Pump Flow: ~204.4 L/min (54 gal/min)
Digging Depth (max): ~6,240 mm for some configurations
Swing Speed: ~11.5 rpm
Track Gauge / Shoe Size: ~2,200 mm (track gauge) / 600 mm shoes
Hydraulic Relief Pressure: ~35,000 kPa
Dimensions: Length (with boom) ~9,450 mm, width ~2,800 mm
Safety / Features:
ROPS / FOPS cab protection
Easy-maintenance access – ground-level service points for oil, filters
Scheduled Oil Sampling (S·O·S) ports for hydraulic / engine oil
Usage Duration
2 years
